Advanced Hybrid Automotive Systems

This book contains a wide array of automotive hybrid applications. Emphasis is placed on a practical approach, with the theory to back it up as well. It is, however, expected that the technician already has a basic understanding of automobiles and electronics in general. The text is also a great companion to in class training. With that in mind, learn and enjoy.Advanced HYBRID Vehicle Systems(vol 1), Including Toyota & Honda modelsBy Mandy ConcepcionTable of ContentsCHAPTER 1 (Hybrid Basics and Safety Procedures)The Need for Hybrid SystemsHybrid Do's and Dont'sHere are some definite do'sHybrid basics and safety proceduresHybrid power down procedure and deactivationHigh voltage measurement and equipmentHumidity and high-voltageCHAPTER 2 (Hybrid Aerodynamics and Low Friction Tires)Low friction components and non-belt driven coolant pump, and air conditioning compressorThe AC systemEPS system, or electric power steeringReplacement of the actual electric motorPerforming a zero rest procedureCHAPTER 3 (Advanced Electronics for Hybrids)The dangers of amperage and High Current CircuitsCurrent measurements using an electromagnetic probe (clamp on)Voltage measurement on hybrid vehicles (advanced concepts)Measure the high voltage circuit at the orange cables after a power down procedureThe Dropping ResistorsCHAPTER 4 (Basic Electric Motor and Power Generation)Principle of InductionElectric Motors and Electric Alternating CurrentThe DC Electric MotorThe AC Electric MotorImportant facts about electric hybrid motor generator unitsTypical hybrid motor generatorDangers of Inverter Internal CapacitorsMotor Commutation PlatesHybrid Motor Position SensorMotor control techniquesDifference between a hybrid vehicle electrical motor and a regular AC motorThe TRIAC and IGBT (Isolated Gate Bipolar Transistor)Hybrid Regenerative BreakingCHAPTER 5 (AC and DC Power Units of Measurements)Frequency measurementsPhase MeasurementVoltage MeasurementsUsing a Clamp-On AMP ProbeThe 3 Phases of a HYBRID Motor (U, V, W)The Inverter Unit on the PriusDC Brushless MotorsCHAPTER 6 (basic battery technology)The nickel metal hydride batteryThe lithium ion batteryToyota Prius high Voltage batteryUltra-CapacitorsV R L A or variable regulation lead acid batteryCHAPTER 7 (The 6 Hybrid Modes of Operation)HYBRID Computer System ControlLight Acceleration ModeRegenerative Breaking ModeDeceleration ModeNormal Driving ModeSTOP ModeM1's Biggest Contribution to the HYBRID UnitCHAPTER 8 (Parallel and Series Hybrid Systems)Series hybrid systemSeries, parallel, and series/parallel hybridInverter Power ManagementParallel hybrid systemParallel/Series hybrid systemToyota motor Co. and AISINCHAPTER 9 (The Prius CVT or continuously variable transmission)THS or hybrid synergy DriveTransmission Planetary GearsKey point to understanding the way this transmission worksHONDA CVT TransmissionHonda's Cylinder DeactivationHonda's Electric BalancingCHAPTER 10 (Toyota specific hybrid system)Specific concepts on the Toyota hybridProblems with the Coolant PumpGas Tank Rubber BladderCar Off AC SystemThe Scanner and the HYBRID SystemHigh Voltage BatteryMG1 and MG2 Power OutputThe Toyota auxiliary 12 V batteryHow to Jump Start a HYBRIDA Word About Toyota's Keyless EntryDangers of Electric Mode DrivingCHAPTER 11 (Honda specific hybrid system)The Honda hybrid system is vastly different than that of ToyotaHONDA Hybrid is a Simpl...
