An Analysis of Nonlinear Elastic Deformations for a Homogeneous Beam at Varying Tip Loads and Pitch Angles

The Princeton beam experiments of 1975 were performed in hopes of producing viable data for beam nonlinear elastic deformation models in hopes of improving helicopter main beam designs. The recorded data, specifically for homogeneous beams of 7075 aluminum, have been referenced as a baseline for the past thirty years to validate numerous computer models and theories in an effort to build beams capable of withstanding aeroelastic, static, and dynamic loading. The purpose of this study is to improve upon the data recorded in 1975 using newer technologies including a laser distance meter, digital inclinometer, and threedimensional traverse to test X-axis, Y-axis, Z-axis and angular displacements for varying tip loads and pitch angles.
