Creo Parametric 2.0: Introduction to Solid Modeling - Part 2

Note: To complete this learning guide, Creo Parametric 2.0: Introduction to Solid Modeling - Part 1 is required.

Learn the process of designing models with Creo Parametric 2.0 from 2D sketching, through to solid part modeling, assembly creation, and drawing production. Gain an understanding of the design philosophy of Creo Parametric 2.0 through this extensive hands-on course with numerous practice exercises.

Topics include:

• Creo Parametric fundamentals and interface
• Principles behind design intent
• Manipulating a model
• Creo Parametric file management
• Part creation and modification
• Sketching and creating geometry
• Sketcher mode functionality (sketching and dimensioning)
• Datum features
• Duplication techniques (patterns, mirroring)
• Creating relations to capture design intent
• Creo Parametric customization
• Design documentation and detailing
• Feature management
• Sweeps and blends
• Assembly creation and manipulation
• Parent/Child relationships in Creo Parametric models
• Model Analysis
• Feature failure resolution
• Effective modeling techniques

Prerequisites:

• Experience in mechanical design and drawing production is recommended.
• Creo Parametric 2.0: Introduction to Solid Modeling - Part 1Please note that this learning guide uses commercial practice files which may not be compatible with the Student Edition of Creo Parametric
