Creo Parametric 5.0: Introduction for Non-Designers

The Creo Parametric 5.0: Introduction for Non-Designers learning guide provides reviewers or downstream users of Creo Parametric data with the knowledge to investigate, manipulate, and annotate existing models. It is targeted at students who require less training about geometry creation techniques. The student learns to open models for the purpose of providing feedback, verification, image capture, and taking data into specialized modules. This learning guide provides a good introduction to Creo Parametric for users who are evaluating the software or need a high-level understanding of software's capabilities.

This guide was developed against Creo Parametric 5.0 Build 5.0.6.0.

Topics Covered

• Creo Parametric interface
• Obtaining model information
• Display control
• Creating datum features
• View manager
• 3D annotations
• Creating planar and offset cross-sections
• View creating and detailing
• File management
