Enovia V5-6r2017: DMU Navigator and Space Analysis

The ENOVIA V5-6R2017: DMU Navigator and Space Analysis student guide is an introduction to the DMU workbenches of the ENOVIA suite of products. Digital Mock-Up (DMU) is used primarily as a viewing and analysis tool for 3D CAD data. Students are introduced to the DMU interface by viewing, manipulating and analyzing 3D model geometry. Specific focus is made on the Space Analysis workbench, which provides access to clash, sectioning, and comparison tools. Based on the results of these analyses, students will learn to create annotations directly on the 3D geometry in order to communicate information back to the designers.

Topics Covered

• DMU user interface
• Model navigation and visualization
• File management
• Measurement tools
• Clash analysis
• Sectioning
• Distance and band analysis
• Compare products
• Arc through three points
• 3D annotations
• Annotation views
• Image capture
• Printing images

Prerequisites

• CATIA V5-6R2017: Introduction to Modeling, or
• CATIA V5-6R2017: Introduction for Managers & Reviewers
