Mechanical Vibrations

MECHANICAL VIBRATIONS by J. P. DEN HARTOG.Originally published in 1917. PREFACE: This book grew from a course of lectures given to students in the Design School of the Westinghouse Company in Pittsburgh, Pa., in the period from 1926 to 1932, when the subject had not yet been introduced into the curriculum of our technical schools. From 1932 until the beginning of the war, it became a regular course at the Harvard Engineering School, and the book was written for the purpose of facilitating that course, being first published in 1934. In its first edition, it was influenced entirely by the authors industrial experience at Westinghouse the later editions have brought modifications and additions suggested by actual problems published in the literature, by private consulting practice, and by service during the war in the Bureau of Ships of the U. S. Navy. The book aims to be as simple as is compatible with a reason ably complete treatment of the subject. Mathematics has not been avoided, but in all cases the mathematical approach used is the simplest one available. In the third edition the number of problems has again been increased, while the principal changes in the text concern subjects in which recent advances have been made, such as airplane wing flutter, helicopter ground vibration, torsional pendulum dampers, singing ships propellers, and electronic instruments. The author expresses his gratitude to the many readers who have written him calling attention to errors and making sugges tions for improvements and hopes that readers of this third edition will also offer suggestions. J P. DEN HAIITOG. CAMBRIDGE, MASS., January, 1947. Contents include: PREFACE. . . LIST OF SYMBOLS CHAPTER I KINEMATICS OF VIBRATION 1. Definitions . 2. The Vector Method of Representing Vibrations 3. Beats 4. A Case of Hydraulic-turbine Penstock Vibration tS 5. Representation by Complex Numbers 11 6. Work Done on Harmonic Motions. . . . . . 14 7. Non-harmonic Periodic Motions. . . . . . 19 CHAPTER II THE SINGLE DEGREE OF FREEDOM SYSTEM 8. Degrees of Freedom 34 9. Derivation of the Differential Equation , 36 10. Other Cases 38 11. Free Vibrations without Damping 43 12. Examples 47 13. Free Vibrations with Viscous Damping . ... 51 14. Forced Vibrations without Damping ... .57 15. Forced Vibrations with Viscous Damping. .... 63 16. Frequency Measuring Instruments. ... ... 72 17. Seismic Instruments .75 18. Electrical Measuring Instruments ... . SO 19. Theory of Vibration Isolation .... ... S9 20. Application to Single-phase Electrical Machinery 92 21. Application to Automobiles Floating Power 96 CHAPTER III Two DEGREES OF FREEDOM 22. Free Vibrations Natural Modes 103 23. The Undamped Dynamic Vibration Absorber 112 24. The Damped Vibration Absorber .119 viii CONTENTS 25. Ship Stabilization by Means of Frahms Tanks 133 26. Gyroscopic Ship Stabilizers 139 26a. Activated Ship Stabilizers 142 27. Automobile Shock Absorbers 145 CHAPTER IV MANY DEGREES OF FREEDOM 28. Free Vibra...
