Mem09208a Detail Fasteners and Locking Devices in Mechanical Drawings

This unit of competency covers the skills and knowledge required to produce detailed engineering drawings containing fastening and locking devices. This unit is suitable for those working within a drafting work environment and can be applied across all engineering disciplines. Drawings will usually be carried out with the use of computer-aided design (CAD) systems but may also be done manually. Drawings are produced to Australian Standard (AS) 1100.101-1992 Technical drawing - General principles, from predetermined critical dimensions and specifications. A CD containing templates for exercises can be obtained by contacting blakline@bigpond.net.au for $10 plus postage.
