Shock Tube Investigation of Pressure and Ion Sensors Used in Pulse Detonation Engine Research

Shock tubes utilize a difference in pressures between gases separated by a diaphragm to create a shock wave when the diaphragm ruptures. By using sensors of known spacing, the speed of the wave can be determined. The AFIT 2-inch shock tube was reassembled and tested to ensure proper and safe operation. A high-speed data acquisition system was configured to take data at 2 MS/s. This research showed that the Mach number of the shock waves produced in this shock tube fall within 7% of theoretical values at speeds under Mach 3 and within 9% at higher speeds. The peak velocity of each shock wave was shown to occur at approximately 3 meters from the diaphragm.
