Cam Design and Manufacturing Handbook

The third edition of Cam Design and Manufacturing Handbook brings together the latest cam design technology, proper cam design methods and manufacturing procedures, and cam research results in one volume that is indispensable to the design, analysis, and manufacturing of cam-follower systems. Much of the material is original and based on 30 years of cam research involving many of the author's graduate students whose theses were advised by the author and on papers published in professional journals. It covers treatments of shape-preserving and B-splines for cams, calculations of 3-D globoidal cams, modeling of multi-DOF cam systems, calculation of torque-compensation cams that can zero the net inertial torque on a cam system's camshaft, and equations to model the deliberate impact of a follower against a valve seat or hard-stop. This edition adds a new chapter on servo-driven mechanisms. The mathematics to program servo drives is the same as that for cam motions, though there are other pitfalls, which are discussed in this chapter. Covering both introductory and advanced topics in depth, this comprehensive handbook provides all the information you need to properly design, model, analyze, specify, and manufacture cam-follower systems including:

Proper Cam Design Techniques                   Roller and Flat Followers

Polydyne and Splinedyne Cams                   Translating and Oscillating Followers

Single- and Multi-Dwell Cams                     Measuring Cam-Follower Dynamics

Classical Cam Functions                               Residual Vibrations

Polynomial and Spline Cams                        Forward and Inverse Dynamic Analysis

Conjugate Cams                                            Lubrication of the Cam-Follower Joint

Pressure Angle and Radius of Curvature      Case Studies of Cam Designs

Radial, Barrel, and Linear Cams                   An Extensive Bibliography on Cams

This book provides all the information a...
